New World Music Hall & Event Venue | Tampa, FL

Technical Specifications | June 2022

Production Manager/Sound Engineer – Paul “Pauly” Babikianpaulybsound@gmail.com

**HAZER / FOGGER USE IS PROHIBITED**

New World Music Hall stage

FOH

Behringer X32 Digital Mixer (full size) with 2 x S16 16/8 Digital Snake (total 32in/16out)
-or-
Soundcraft Si Expression 3 Digital Mixing Console with MiniStagebox 32in/16out (8analog/8aes)

http://www.soundcraft.com/products/Si-Expression-3

MAIN PA

4 x L’Acoustics A15i 2/side (1 Focus & 1 Wide/side)
2 x L’Acoustics KS21i 1/side
1 x L’Acoustics LA4X Amplified Controller (1000W/ch @ 4 & 8 ohms)

MONITORS

4 MIXES FROM FOH CONSOLE
2 x JBL PRX 712 Powered Speakers (Stage Left & Stage Right)
2 x JBL PRX 715 Powered Speakers (Center and Drumfill)

MICROPHONES

1 x Shure Beta 52A
1 x Sennheiser e602
4 x Sennheiser e604
2 x Sennheiser e614
5 x Sennheiser e835
Assorted microphone stands, xlr cables, DI boxes, etc.

Also available additional mics by Telefunken (M80/SH, M81/SH), AKG (D5/D5C, D40, C1000, C3000, C435), and Sennheiser (e901, e902, e906)

LIGHTING

1 x Chauvet DMX-40B Obey 40 DMX Controller
12 x Chauvet SlimPAR 56 LED
4 x PAR 64 LED

STAGE DIMENSIONS

22ft / 6.7m wide x 12ft / 3.7m deep x 2ft/ .61m high
CLEARANCE: 13ft / 4m (stage floor to ceiling)
BACKDROP HANG POINT: 9ft / 2.7m high x 22ft / 6.7m wide

HAZER / FOGGER USE IS PROHIBITED

New World Biergarten Stage

BIERGARTEN STAGE

Soundcraft Ui16 (12xlr in/4xlr out (w/iPad for control)
2 x JBL Eon 15 powered speaker (2nd generation) for mains
1 x Mackie Thump 12A powered speaker (new version) for outfill
1 x Mackie Thump 12 powered speaker (original version) for monitor
